Rama:
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew (Size XS: curved top tube)
Prednja vilica:
RockShox Judy Silver, Solo Air spring, rebound adjust, TurnKey hydraulic lockout, 46 mm offset for 29" wheel, 100 mm QR, 100 mm travel (Size XS, S: 42 mm offset for 27.5" wheel, 100 mm travel)
Prednja glavčina:
Formula DC-20 LW, alloy, 6-bolt, 5x100 mm QR
Zadnja glavčina:
Formula DC-22LW, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Obruči:
Bontrager Kovee, double-wall, Tubeless-Ready, 32-hole, 23 mm width, Presta valve
Žbice:
14 g stainless steel
Gume:
Maxxis Rekon, tubeless ready, EXO casing, folding bead, 60 tpi, 29x2.40'' (Size XS & S: 27.5x2.40'')
Ručice mjenjača:
SRAM SX Eagle, 12-speed
Zadnji mjenjač:
SRAM NX Eagle, 12-speed
Pogon:
SRAM SX Eagle, 30T steel ring, 49 mm chainline, 175 mm length (Size: XS, S, M: 170 mm length)
Osovina pogona:
Truvativ Powerspline, 73 mm, threaded cartridge, 118 mm spindle
Kazeta:
SRAM PG-1210 Eagle, 11-50, 12-speed
Lanac:
SRAM SX Eagle, 12-speed
Pedale:
VP-536 nylon platform
Sjedalo:
Bontrager Verse Short, stainless steel rails
Cijev sjedala:
TranzX JD-YSI34, 150 mm travel, internal routing, 34.9 mm, 456 mm length (Size: XS , S: 350 mm length; Size: M: 405 mm length; Size: XL, XXL: 500 mm length)
Kormilo:
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width (Size: XS: 5mm rise, 690 mm width; Size: S: 15mm rise, 720 mm width)
Navlake kormila:
Trek Line Comp, nylon lock-on
Lula kormila:
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length (Size XS, S: 35 mm length; Size M, M/L, L: 50 mm length; Size XL: 60 mm length)
Garnitura vilice:
Semi-integrated, 1-1/8"
Kočnice:
Shimano MT200 hydraulic disc
Težina:
M - 14.15 kg / 31.2 lbs
