Rama:
Alpha Silver Aluminium, internal derailleur and dropper post routing, rack and kickstand mount, 135x5 mm ThruSkew (Size XS: curved top tube)
Prednja vilica:
SR Suntour XCT 30, coil spring, preload, hydraulic lockout, 42 mm offset for 29" wheel, 100 mm QR, 100 mm travel (Size XS: 42 mm offset for 27.5" wheel, 80 mm travel; Size S: 42 mm offset for 27.5" wheel, 100 mm travel)
Prednja glavčina:
Formula DC-20, alloy, 6-bolt, 5x100 mm QR
Zadnja glavčina:
Formula DC-22, alloy, 6-bolt, Shimano 8/9/10 freehub, 135x5 mm QR
Obruči:
Bontrager Connection, double-wall, 32-hole, 20 mm width, Schrader valve
Žbice:
14 g stainless steel
Gume:
Bontrager Montrose comp, wire bead, 30 tpi, 29x2.40" (Size XS & S: 27.5x2.40")
Ručice mjenjača:
Shimano U4000, 9-speed
Zadnji mjenjač:
Shimano CUES U4000
Pogon:
Shimano CUES U4001, 32T, 52mm chain line, 175mm length (Size: XS, S, M, M/L: 170 mm length)
Osovina pogona:
Shimano, 73 mm, threaded cartridge, 122.5 mm spindle
Kazeta:
Shimano LINKGLIDE LG300, 11-46, 9-speed
Pedale:
VP-536 nylon platform
Sjedalo:
Bontrager Verse Short, stainless steel rails
Cijev sjedala:
Bontrager alloy, 31.6 mm, 12 mm offset, 400 mm length (Size: XS , S , M: 330 mm length)
Kormilo:
Bontrager alloy, 31.8 mm, 15 mm rise, 750 mm width (Size: XS: 5mm rise, 690 mm width; Size: S: 15mm rise, 720 mm width)
Navlake kormila:
Trek Line Comp, nylon lock-on
Lula kormila:
Bontrager Comp, 31.8 mm, Blendr compatible, 7-degree, 70 mm length (Size XS, S: 35 mm length; Size M, M/L, L: 50 mm length; Size XL: 60 mm length)
Garnitura vilice:
Semi-integrated, 1-1/8"
Kočnice:
Shimano MT200 hydraulic disc
Težina:
M - 15.10 kg / 33.29 lbs
