Rama:
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Prednja vilica:
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Prednji kotač:
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
Zadnji kotač:
Bontrager Aeolus Pro 51, OCLV Carbon, Tubeless Ready, Shimano 11/12-speed freehub, 142x12 mm thru axle
Gume:
Bontrager R3 Hard-Case Lite, Tubeless Ready, aramid bead, 170 tpi, 700x28 mm
Ručice mjenjača:
Shimano Ultegra R8170 Di2, 12-speed
Prednji mjenjač:
Shimano Ultegra R8150 Di2, braze-on, down swing
Zadnji mjenjač:
Shimano Ultegra R8150 Di2, 34T max cog
Pogon:
Shimano Ultegra R8100, 50/34 (Size: XS, S: 165 mm length; Size: M, ML: 170 mm length; Size: L, XL: 172.5 mm length)
Osovina pogona:
Praxis, T47 threaded, internal bearing
Kazeta:
Shimano Ultegra R8101, 11-30, 12-speed
Lanac:
Shimano Ultegra/XT M8100, 12-speed
Sjedalo:
Bontrager Aeolus Elite, austenite rails
Cijev sjedala:
Madone aero carbon seat post, 0 mm offset
Kormilo:
Bontrager Aero Pro, OCLV Carbon, 31.8 mm, Di2 routing, 80 mm reach, 124 mm drop
Navlake kormila:
Bontrager Supertack Perf tape
Lula kormila:
Trek RCS Pro, -7-degree
Kočnice:
Shimano Ultegra hydraulic disc, BR-R8170 flat mount caliper
Težina:
ML - 7.87 kg / 17.36 lbs (with TLR sealant, no tubes)
Extra:
Shimano Di2 Charging cable included
