Rama:
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Prednja vilica:
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Prednji kotač:
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 100x12 mm thru axle
Zadnji kotač:
Bontrager Aeolus Elite 50, OCLV Carbon, Tubeless Ready, 50 mm rim depth, Shimano 11-speed freehub, 142x12 mm thru axle
Gume:
Bontrager Aeolus Pro, Tubeless Ready, aramid bead, 120 tpi, 700x28 mm
Ručice mjenjača:
SRAM Rival AXS, 12-speed
Prednji mjenjač:
SRAM Rival AXS, braze-on
Zadnji mjenjač:
SRAM Rival AXS, 36T max cog
Pogon:
SRAM Rival AXS, 48/35, DUB (Size: XS, S: 165 mm length; Size: M, ML: 170 mm length; Size: L, XL: 172.5 mm length)
Osovina pogona:
SRAM DUB, T47 threaded, internal bearing
Kazeta:
SRAM XG-1250, 10-36, 12-speed
Lanac:
SRAM Rival E1, 12/13-speed
Sjedalo:
Bontrager Aeolus Elite, austenite rails, 145 mm width
Cijev sjedala:
Madone aero carbon seat post, 0 mm offset
Kormilo:
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop
Navlake kormila:
Trek EcoTack
Lula kormila:
Trek RCS Pro, -7-degree
Kočnice:
SRAM Rival hydraulic disc
Težina:
ML - 8.11 kg / 17.88 lbs (with TLR sealant, no tubes)
