Rama:
500 Series OCLV Carbon, Full System Foil tube shaping, IsoFlow seat tube, RCS Headset System, electronic or mechanical routing, removable aero chain keeper, T47 BB, flat mount disc, UDH, 142x12 mm thru axle
Prednja vilica:
Madone Gen 8 full carbon, tapered carbon steerer, internal brake routing, flat mount disc, 12x100mm chamfered thru axle
Prednja glavčina:
Bontrager alloy, sealed bearing, CenterLock disc, 100x12 mm thru axle
Zadnja glavčina:
Bontrager alloy, sealed bearing, CenterLock disc, Shimano 11-speed freehub, 142x12 mm thru axle
Obruči:
Bontrager Paradigm 23, Tubeless Ready, 24-hole, 23 mm width, Presta valve
Gume:
Bontrager R1 Hard-Case Lite, wire bead, 60 tpi, 700x28 mm
Ručice mjenjača:
Shimano 105 R7120, 12-speed
Prednji mjenjač:
Shimano 105 R7100, braze-on, down swing
Zadnji mjenjač:
Shimano 105 R7100, 36T max cog
Pogon:
Shimano 105 R7100, 50/34 (Size: XS, S: 165 mm length; Size: M, ML: 170 mm length; Size: L, XL: 172.5 mm length)
Osovina pogona:
Praxis, T47 threaded, internal bearing
Kazeta:
Shimano 105 7101, 11-34, 12-speed
Lanac:
Shimano SLX M7100, 12-speed
Sjedalo:
Bontrager Aeolus Elite, austenite rails, 145 mm width
Cijev sjedala:
Madone aero carbon seat post, 0 mm offset
Kormilo:
Bontrager Comp, alloy, 31.8 mm, 80 mm reach, 121 mm drop
Navlake kormila:
Trek EcoTack
Lula kormila:
Trek RCS Pro, -7-degree
Kočnice:
Shimano 105 hydraulic disc, flat mount
Težina:
ML - 8.64 kg / 19.05 lbs (with tubes)
