BIKE SPECS...
Frame
E5 Aluminum, bottom bracket motor mount, fully integrated &lockable downtube battery, internal cable routing, lock and front rack mount
Fork
Rockshox Recon Silver RL, 110mm travel, Motion-Control
Tape
Specialized Trail Grips, Lock-on
Stem
Stout 3D-forged alloy, 31.8mm, 6-degree rise
Handlebars
Specialized Trail, 6061 alloy, 8-degree backsweep, 6-degree upsweep, 27mm rise, 31.8mm clamp, S 720mm, M-XL 750mm
Front Brake
SRAM G2 RS, 4-piston caliper, hydraulic disc, 200mm
Rear Brake
SRAM G2 RS, 4-piston caliper, hydraulic disc, 180mm
Rear Derailleur
SRAM GX, long cage, 11-speed
Shift Levers
SRAM S700, single-click lever
Chain
KMC e11T, 11-speed w/ Missing Link™
Crankset
Custom alloy forged crankarms
Cassette
SRAM PG-1130, 11-speed, 11-42t
Chainrings
Praxis, 36T, 104BCD
Pedals
Specialized platform pedal
Rims
Stout XC 29, 25mm internal width, disc-specific
Front Hub
Specialized alloy front hub disc, sealed cardridge bearings, 6-bolt, 15x110mm thru-axle, 32h
Rear Hub
Specialized alloy rear hub disc, sealed cardridge bearings, 6-bolt, 12x148mm thru-axle, 32h
Front Tire
Ground Control, 2Bliss Ready, 29x2.35"
Rear Tire
Ground Control, 2Bliss Ready, 29x2.35"
Inner Tubes
Presta, 48mm valve
SeatPost
TranzX Dropper, 30.9mm, S: 100mm, M-XL: 120mm
Saddle
Rivo Sport, steel rails, 155mm
Seat Binder
Specialized Alloy, 34.9mm
Motor
Specialized 2.2, 90Nm torque, custom tuned motor, 250W nominal
UI/Remote
MasterMind TCD, w/handlebar remote, built-in anti-theft feature, Bluetooth® connectivity, customizable display pages
Battery
Specialized U2-710, alloy casing, state of charge display, 710Wh
Charger
Custom charger, 42V4A w/ Rosenberger plug, 230V
Wiring Harness
Custom wire harness
