Frame
M5 alloy, Style-Specific DH Geometry, horst pivot flip chip for 27.5 or 29 rear wheel, BSA threaded BB, full internal cable routing with option for full external brake, 148mm rear spacing, sealed cartridge bearing pivots, replaceable derailleur hanger, 200mm of travel
Seat Binder
Alloy, 34.9mm
Fork
Öhlins DH38 M.1 29, TTX Twin Tube Damping, external low speed rebound adjust, external high and low speed compression adjustment, 20x110mm, 58mm offset, 200mm of travel
Rear Shock
Öhlins TTX 22 M Coil, external rebound adjust, external high and low speed compression adjustment, Trunnion mount, 225x75
Saddle
Body Geometry Henge DH, hollow titanium rails, 130mm
Grips
Deity, Lockjaw
Handlebars
Renthal Fatbar 35, 5-degree upsweep, 7-degree backsweep, 30mm rise, 800mm, 35.0mm
Stem
Renthal Integra 35mm Direct Mount Stem, 45mm length
SeatPost
Thomson, alloy, straight, 12-degree clamp
Front Brake
SRAM Code RSC, 4-piston caliper, hydraulic disc, 220mm HS2
Rear Brake
SRAM Code RSC, 4-piston caliper, hydraulic disc, 200mm HS2
Bottom Bracket
SRAM DUB, 83mm
Cassette
SRAM X01 DH, 7-speed, 10-24t
Rear Derailleur
SRAM X01 DH, 7-speed, trigger
Crankset
SRAM X01 DH, DUB, carbon, Direct mount ring, 165mm
Shift Levers
SRAM X01 DH, trigger, 7-speed
Chain
Sram PC1130 w/ Powerlink, 11-speed
Chainrings
34T
Rims
Roval Traverse Alloy 29" / 27.5", 32h alloy rim, 28mm inner rim width
Front Hub
DT Swiss 350 hub, 20x110mm
Front Tire
Cannibal, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 29x2.3"
Rear Tire
Cannibal, GRID GRAVITY casing, GRIPTON® T9 compound, 2Bliss Ready, 27.5x2.3"
Spokes
Sapim D-Light
Rear Hub
DT Swiss 350 hub, 12x148mm
Inner Tubes
Standard, Presta
Weight
17.56kg (38 lb, 11.4 oz)
Weight Size
S3
* Weights based on production painted frames as pictured. Actual weights will vary based on colourway, frame size, and component variation. Specifications are subject to change without notice.
