| Motor |
Bosch Drive Unit Performance Line CX 85Nm (BDU38), Smart System |
| Baterija |
Bosch PowerTube 800 |
| Punjač |
Bosch 4A |
| Display (zaslon) |
Bosch Purion 400 |
| Okvir |
C:62® Monocoque Advanced Twin Mold Technology, Aluminium 6061 T6 Rear Triangle, Efficient Trail Control, FSP 4-Link, Agile Trail Geometry, Boost 148, UDH™, Full Integrated Battery, Advanced Internal Cable Routing |
| Vilica |
Fox 36 Float Rhythm, 2-Position Sweep-Adjust GRIP Damper, Tapered, 15x110mm, E-Bike Optimized, 150mm |
| Ležaj vilice |
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment, X-Connect Interface |
| Stražnja suspenzija |
Fox Float Performance, 230x60mm (27.5: 210x55mm), Open/Firm Mode, Front: 30x8mm, Rear: DU-Bushing 12,7mm |
| Lula volana |
CUBE Performance Stem E-MTB 35, FPI-Link |
| Volan |
CUBE Rise Trail Bar 35 |
| Gripovi / Traka volana |
ACID Disrupt |
| Stražnji mjenjač |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Ručice mjenjača |
Shimano XT SL-M8100-IR, Direct Attach |
| Kočnice |
Shimano XT BR-M8120, Hydr. Disc Brake (203/203) |
| Pogon |
ACID MTB Hybrid Pro, 27.5: 36T // 29: 34T |
| Lanac |
KMC e12 |
| Vodilica lanca |
Reverse Flip-Guide E-Chain Guide, Direct Mount, I-Plate |
| Kazeta |
Shimano Deore CS-M6100, 10-51T |
| Obruči / Kotači |
Newmen Performance 30, 28/32 Spokes (Base/Strong), 15x110mm / 12x148mm, Tubeless Ready |
| Vanjske gume |
F: Schwalbe Hans Dampf, Addix Soft, Super Trail, Tubeless Easy, 2.6, B: Schwalbe Hans Dampf, Addix Speedgrip, Super Trail, Tubeless Easy, 2.6 |
| Sjedalo |
ACID Venec EMTB Trail 140 |
| Cijev sjedala |
CUBE Dropper Post, Handlebar Lever, Internal Cable Routing, 31.6mm |
| Težina |
24,4 kg |
