| Okvir |
C:62® Monocoque Advanced Twin Mold Technology, Boost 12x148mm, Full Internal Cable Routing, Dropper Post ready, UDH™ |
| Vilica |
RockShox SID SL Base, Tapered, 15x110mm, 100mm |
| Ležaj vilice |
ACROS AZF-675, ICR (Integrated Cable Routing), Top Zero-Stack 1 1/2" (ZS 56mm), Bottom Zero-Stack 1 1/2" (ZS 56mm), Fiber Inserts for Angle Adjustment |
| Lula volana |
Newmen Evolution 318.4, 31.8mm |
| Volan |
Newmen Evolution SL 318.10, 760mm |
| Gripovi / Traka volana |
ACID React Pro |
| Stražnji mjenjač |
Shimano XT RD-M8100-SGS, ShadowPlus, 12-Speed |
| Ručice mjenjača |
Shimano XT SL-M8100-IR, Direct Attach |
| Kočnice |
Shimano XT BR-M8100, Hydr. Disc Brake (160/180) |
| Osovina pogona |
Shimano BB-MT500PA, 92mm Pressfit |
| Pogon |
Shimano FC-MT611, 32T, Boos |
| Lanac |
Shimano CN-M6100 |
| Kazeta |
Shimano Deore CS-M6100, 10-51T |
| Obruči / Kotači |
Newmen Performance 30 light/light, 28/28 Spokes, 15x110mm/12x148mm, Tubeless Ready CUBE Engineered By Newmen, 15mm, Boost, Centerlock |
| Vanjske gume |
F: Schwalbe Racing Ray, Addix Performance, Kevlar, 2.25, R: Schwalbe Racing Ralph, Addix Performance, Kevlar, 2.25 |
| Sjedalo |
ACID Nuance Lite |
| Cijev sjedala |
Newmen Evolution, 27.2mm |
| Težina |
10,8 kg |
